SIPhon

A high-performance SIP proxy, B2BUA, and IMS platform — a Kamailio/OpenSIPS-class protocol engine, scripted in Python instead of a config DSL.

SIPhon is written in Rust — the transports, the RFC 3261 transaction and dialog state machines, the registrar — and scripted in free-threaded Python, which decides policy. You get the parts that are genuinely hard to get right as a fast, memory-safe core, and you drive them with real code:

  • Python, not a config language — real functions, imports, a debugger, and pytest (with a mock SDK) instead of $avp expansions and failure_route chains.
  • One YAML file for config — documented inline, no modparam.
  • Hot-reload — edit a script, save, done. No restart.
  • The B2BUA is first-class — two independent dialogs, topology hiding, media anchoring, header policies, forking — in ~50 lines of readable Python.
  • Fast — tens of thousands of calls per second per node (~28–30k cps on commodity hardware), so you usually add nodes for redundancy, not throughput.
from siphon import b2bua, gateway

@b2bua.on_invite
def on_invite(call):
    call.media.anchor(engine="rtpengine")      # hide the media path
    call.remove_headers_matching("^X-")         # strip internal headers
    call.dial(gateway.select("carriers").uri)   # bridge to a trunk

That's a topology-hiding SBC with media anchoring. More like it in the Cookbook.

New here? Start with the Cookbook

The Cookbook has complete, working starting points for the common roles — each with the config, a real script, and how to test it:

Registrar · Stateful proxy · Load balancer · SBC (B2BUA) · Media & RTP profiles · Hardening & security · Monitoring

Running it in production

  • Scaling, clustering & redundancy — how to run more than one node, what shared state actually means here, what the Redis backend buys you (durability + boot snapshot, not live cross-node sync), and why SIPhon ships no clusterer/DMQ-style replication engine. Start here if you're asking "how does SIPhon cluster?"
  • Deployment & operations — concrete topologies (single node, redundant pair / N nodes, IMS), the ops runbook (graceful drain, health/readiness probes, metrics & alerting, capacity planning, backup/DR), and a light Kubernetes shape.
  • Migrating from Kamailio / OpenSIPS — a concept map for porting routes and modules, and how to translate clusterer / dmq_usrloc topologies to SIPhon's model.

Internals

  • Handler execution model — how Python handlers run, the blocking contract, and the elasticity / backpressure / liveness guarantees of the handler pool.
  • Feature readiness matrix — per-feature maturity (Production / Implemented / Planned) with config keys and validation notes.

Runnable deployments

Reference deployment artifacts — a front-LB + 2-backend demo with a failover-proof script, plus Kubernetes manifests — live in deploy/.

Also

  • The main README — overview, install, full scripting API, performance baseline.
  • siphon.yaml — the annotated reference configuration.
  • sdk/ — the siphon-sip mock library for testing scripts.
